What is a Skeg in a Vessel?

A skeg in a vessel is an important but not a necessary component. A skeg is a vertical tapering projection or an external structural feature at the aft of the vessel, about the centreline, directly attached to the vessel’s bottom shell plating, and mostly, but not necessarily, situated in front of the rudder. As it is not intrinsic to the main hull structure, it can be said as an appendage for all practical purposes.

It may also be defined as the sternward extension of the keel in the exterior of the main hull. (Keel being one of the main internal longitudinal strength members contributing to the global strength of the hull).

Skeg

Beyond a certain point in the aft (and the front as well), the plating of the hull rises above the baseline as per the hull’s curvature in profile view.

So, the keel plate, which has the highest scantlings in the bottom shell and the central longitudinal bottom girder, rises to the curvature.

So, the skeg, which projects or juts out linearly from the hull’s bottom curvature, can be said to be a member in direct connectivity and linear extension (outside) with the flat shell plating.

Full Skeg Rudder (Unbalanced)
Fig.1: Full Skeg Rudder (Unbalanced)

In geometry, it is characteristic of a tapering projection (broader at the top and narrower at the bottom) when viewed in a transverse direction and a flat lateral surface when viewed from the sides or in a longitudinal manner. In terms of construction, it is usually composed of two large lateral side flat plates attached longitudinally to the bottom shell and connected in between by a successive series of transverse intermediate plates, which are of the aforementioned tapering shape.

The lower extremity of the skeg is composed of another flat closing plate and connects the two side lateral plates as well as welded to the interspersing transverse plates. Other additional structural and supporting or strengthening members are also present as per requirement. In the front end of the skeg, there is usually a slanted vertical plate that is attached to the bottom shell plating, known as the backplate or faceplate.

Semi-balanced skeg rudder
Fig 2: Semi-balanced skeg rudder

The transverse tapering plates are mostly for structurally supporting the skeg. The scantlings of the skeg are usually on the higher side as it is not only an external structure but also is subject to the high modulus of loads and pressures stemming from the waves, currents, as well as potential risks of contact with any type of surface during grounding/accidental damage.

Semi-balanced, aft of skeg or deadwood
Fig 3: Semi-balanced, aft of skeg or deadwood

Again, from a geometric point of view, the principal parameters of a skeg can be best defined by A, the face area or the lateral area of the side plates, and t, the mean breadth of any of its cross sections in a transverse view (as sectionally it is tapering and the mean breadth is taken accordingly). For all practical purposes, because of its design and construction, a skeg has a high A/t ratio which means that the area-to-breadth proportion is quite large, as evident, or in other words, a skeg is a very slender structure.

Applications of skeg and some details

1. Hydrodynamics

The most important reason for a skeg is the hydrodynamics. In simple words, the design of the skeg dramatically influences the flow patterns, and this, in turn, affects the dynamics related to the rudder (which is usually in line with the skeg) and the propeller(s). This improved flow pattern reduces drag and resistance. Moreover, the propeller efficiency also increased. Another important aspect under consideration is turbulence. Skegs have been experimentally as well as practically proven to be instrumental in reducing turbulence by tending to transform the turbulent characteristics of the flow to laminar at the stern.

2. Directionality and seakeeping

This is also another very crucial aspect. Skegs can be best compared to the tailfins in planes in this respect, with the difference being that in the latter, they are mandatory. In contrast, in ships, they are not as ships speeds are relatively much lesser and have the stable buoyant support of the water, so losing directionality (if any) is not very sudden and drastic as well as risky.

In older vessels, especially smaller ones, skegs were common to maintain course and not veer away. However, in modern and bigger vessels, due to improved rudder and advanced navigational as well as stabilisation technologies like thrusters or DPS, skegs are not very important from a course-keeping point of view.

Nonetheless, skegs have been found to be useful in yaw control and reducing sway motions as well. Furthermore, skegs also play an important role in seakeeping by improvising stability and vertical balance characteristics like increasing roll damping. So, to date, skegs are incorporated in designs of many vessels, especially finer-form ones with low displacements.

3. Strength, protection, and support

Though it is not an intrinsic part of the structural members of a vessel, it definitely contributes to the longitudinal strength. It also provides a significant amount of support not only to the outer hull plating but also to the rudder and propeller as well during events of grounding but absorbing loads. During regular operations like drydock as well, it is also useful in supporting the hull when it rests on a solid surface.

Sometimes, skegs may be ballasted as well. They can also bear stern tubes for the aft propeller shafts in some designs.

Skegs are usually welded to the outer hull at the last stages of construction.
